specifications
Market: |
Turf |
---|---|
Tank Size (L): |
400 |
Connection Type: |
Tray Mount |
Pump Size (L/min): |
58 |
Application: |
For spraying turf. |
Tray Size : |
Suited to 1.2m x 1.4m tray |
Product Enquiry
Find Your Nearest Dealer
Key Features
Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. BP60/20: 58 L/min capacity, 2000kPa pressure, direct driven by 5.5HP Honda with 6.1 reduction gear box.
3 section electric valves. Control box with pressure adjustment and on/off switches mounted on arm close to operator.
Fully galvanised RHS steel sled frame for fitment into tray body. Removable stand legs when not in use.
